Round Electromagnets

Flat-faced round electromagnets or holding solenoids from 0.50″ to 4.0″ dia. These APW electromagnets or holding solenoids available With a wide range of options and holding forces. All made in the USA with manufacturing factory direct support. – – – (if you don’t find it, we can make it)

Round holding solenoid electromagnets are Available with several options;

  • Voltages from 3 vdc to 230 ac
  • Quick Release options (center post recessed .003-.005″ for air gap at surface)
  • Encapsulated or Non-Encapsulated coils
  • Anti-Rotation (rear offset dowel pins)
  • Thru mounting from Front with cap head screw or Rear tapped threaded mounting
Filter

Filter Products

Availability +
Price +
AMPS +
Height (in) +
Diameter (mm) +
Diameter (in) +
BREAK AWAY FORCE (LBS) +
VOLTAGE +
current +
OPTION - QUICK RELEASE GAP +
OPTION - ENCAPSULATED COI +
OPTION - ANTI-ROTATION PIN +
OPTION - MOUNTING +
Showing 61–72 of 202 results
Image Details Outer Dia. (in) Height (in) Voltage Holding Force (lbs) Price Add to cart
EM300-230ac-212 - Round Electromagnet 3 inch Dia. 230 volts AC - Holding 400 lbs. image 0 EM300-230ac-212 - Round Electromagnet 3 inch Dia. 230 volts AC - Holding 400 lbs.
Outer Dia. (in): 3
Height (in): 1.5
Voltage: 230
Holding Force (lbs): 400
$114.02
3 1.5 230 400 $114.02
EM300-3-212 - Round Electromagnet 3 inch Dia. 3 volts DC - Holding 400 lbs. image 0 EM300-3-212 - Round Electromagnet 3 inch Dia. 3 volts DC - Holding 400 lbs.
Outer Dia. (in): 3
Height (in): 1.5
Voltage: 3
Holding Force (lbs): 400
$95.80
3 1.5 3 400 $95.80
EM237-115ac-112 - Round Electromagnet 2.37 inch Dia. 115 volts AC - Holding 170 lbs. image 0 EM237-115ac-112 - Round Electromagnet 2.37 inch Dia. 115 volts AC - Holding 170 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 115
Holding Force (lbs): 170
$77.21
2.37 0.98 115 170 $77.21
EM237-24-112 - Round Electromagnet 2.37 inch Dia. 24 volts DC - Holding 170 lbs. image 0 EM237-24-112 - Round Electromagnet 2.37 inch Dia. 24 volts DC - Holding 170 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 24
Holding Force (lbs): 170
$63.49
2.37 0.98 24 170 $63.49
EM237-12-212 - Round Electromagnet 2.37 inch Dia. 12 volts DC - Holding 190 lbs. image 0 EM237-12-212 - Round Electromagnet 2.37 inch Dia. 12 volts DC - Holding 190 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 12
Holding Force (lbs): 190
$61.49
2.37 0.98 12 190 $61.49
EM237-12-112 - Round Electromagnet 2.37 inch Dia. 12 volts DC - Holding 170 lbs. image 0 EM237-12-112 - Round Electromagnet 2.37 inch Dia. 12 volts DC - Holding 170 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 12
Holding Force (lbs): 170
$63.49
2.37 0.98 12 170 $63.49
EM237-6-112 - Round Electromagnet 2.37 inch Dia. 6 volts DC - Holding 170 lbs. image 0 EM237-6-112 - Round Electromagnet 2.37 inch Dia. 6 volts DC - Holding 170 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 6
Holding Force (lbs): 170
$63.49
2.37 0.98 6 170 $63.49
EM237-115ac-212 - Round Electromagnet 2.37 inch Dia. 115 volts AC - Holding 190 lbs. image 0 EM237-115ac-212 - Round Electromagnet 2.37 inch Dia. 115 volts AC - Holding 190 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 115
Holding Force (lbs): 190
$75.21
2.37 0.98 115 190 $75.21
EM200-115ac-212-A – Round Electromagnet 2 inch Dia. 115 volts AC – Holding 140 lbs. image 0 EM200-115ac-212-A – Round Electromagnet 2 inch Dia. 115 volts AC – Holding 140 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 115
Holding Force (lbs): 140
$69.63
2 1.18 115 140 $69.63
EM237-24-212 - Round Electromagnet 2.37 inch Dia. 24 volts DC - Holding 190 lbs. image 0 EM237-24-212 - Round Electromagnet 2.37 inch Dia. 24 volts DC - Holding 190 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 24
Holding Force (lbs): 190
$61.49
2.37 0.98 24 190 $61.49
EM237-6-212 - Round Electromagnet 2.37 inch Dia. 6 volts DC - Holding 190 lbs. image 0 EM237-6-212 - Round Electromagnet 2.37 inch Dia. 6 volts DC - Holding 190 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 6
Holding Force (lbs): 190
$61.49
2.37 0.98 6 190 $61.49
EM200-12-122-A - Round Electromagnet 2 inch Dia. 12 volts DC - Holding 105 lbs. image 0 EM200-12-122-A - Round Electromagnet 2 inch Dia. 12 volts DC - Holding 105 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 12
Holding Force (lbs): 105
$41.61
2 1.18 12 105 $41.61
Showing 61–72 of 202 results
