Round Electromagnets

Flat-faced round electromagnets or holding solenoids from 0.50″ to 4.0″ dia. These APW electromagnets or holding solenoids available With a wide range of options and holding forces. All made in the USA with manufacturing factory direct support. – – – (if you don’t find it, we can make it)

Round holding solenoid electromagnets are Available with several options;

  • Voltages from 3 vdc to 230 ac
  • Quick Release options (center post recessed .003-.005″ for air gap at surface)
  • Encapsulated or Non-Encapsulated coils
  • Anti-Rotation (rear offset dowel pins)
  • Thru mounting from Front with cap head screw or Rear tapped threaded mounting
Filter

Filter Products

No filters available yet.
Showing 37–48 of 203 results
Image Details Outer Dia. (in) Height (in) Voltage Holding Force (lbs) Price Add to cart
EM200-12-222-A - Round Electromagnet 2 inch Dia. 12 VDC - Holding 140 lbs. image 0 EM200-12-222-A - Round Electromagnet 2 inch Dia. 12 VDC - Holding 140 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 12
Holding Force (lbs): 140
$41.61
2 1.18 12 140 $41.61
EM237-24-212 - Round Electromagnet 2.37 inch Dia. 24 volts DC - Holding 190 lbs. image 0 EM237-24-212 - Round Electromagnet 2.37 inch Dia. 24 volts DC - Holding 190 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 24
Holding Force (lbs): 190
$61.49
2.37 0.98 24 190 $61.49
EM237-6-212 - Round Electromagnet 2.37 inch Dia. 6 volts DC - Holding 190 lbs. image 0 EM237-6-212 - Round Electromagnet 2.37 inch Dia. 6 volts DC - Holding 190 lbs.
Outer Dia. (in): 2.37
Height (in): 0.98
Voltage: 6
Holding Force (lbs): 190
$61.49
2.37 0.98 6 190 $61.49
EM200-24-122-A - Round Electromagnet 2 inch Dia. 24 volts DC - Holding 105 lbs. image 0 EM200-24-122-A - Round Electromagnet 2 inch Dia. 24 volts DC - Holding 105 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 24
Holding Force (lbs): 105
$41.61
2 1.18 24 105 $41.61
EM200-115ac-222-A - Round Electromagnet 2 inch Dia. 115 volts AC - Holding 140 lbs. image 0 EM200-115ac-222-A - Round Electromagnet 2 inch Dia. 115 volts AC - Holding 140 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 115
Holding Force (lbs): 140
$61.72
2 1.18 115 140 $61.72
EM200-220ac-112-A - Round Electromagnet 2 inch Dia. 220 volts AC - Holding 105 lbs. image 0 EM200-220ac-112-A - Round Electromagnet 2 inch Dia. 220 volts AC - Holding 105 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 220
Holding Force (lbs): 105
$70.55
2 1.18 220 105 $70.55
EM200-12-112 - Round Electromagnet 2 inch Dia. 12 volts DC - Holding 105 lbs. image 0 EM200-12-112 - Round Electromagnet 2 inch Dia. 12 volts DC - Holding 105 lbs.
Outer Dia. (in): 2
Height (in): 1.18
Voltage: 12
Holding Force (lbs): 105
$53.21
2 1.18 12 105 $53.21
EM175-12-212 - Round Electromagnet 1.75 inch Dia. 12 volts DC - Holding 100 lbs. image 0 EM175-12-212 - Round Electromagnet 1.75 inch Dia. 12 volts DC - Holding 100 lbs.
Outer Dia. (in): 1.75
Height (in): 1.25
Voltage: 12
Holding Force (lbs): 100
$38.11
1.75 1.25 12 100 $38.11
EM175-12-222 - Round Electromagnet 1.75 inch Dia. 12 volts DC - Holding 100 lbs. image 0 EM175-12-222 - Round Electromagnet 1.75 inch Dia. 12 volts DC - Holding 100 lbs.
Outer Dia. (in): 1.75
Height (in): 1.25
Voltage: 12
Holding Force (lbs): 100
$38.13
1.75 1.25 12 100 $38.13
EM150-6-222 - Round Electromagnet 1.5 inch Dia. 6 volts DC - Holding 88 lbs. image 0 EM150-6-222 - Round Electromagnet 1.5 inch Dia. 6 volts DC - Holding 88 lbs.
Outer Dia. (in): 1.5
Height (in): 1.05
Voltage: 6
Holding Force (lbs): 88
$30.62
1.5 1.05 6 88 $30.62
EM137-24-212 - Round Electromagnet 1.375 inch Dia. 24 volts DC - Holding 44 lbs. image 0 EM137-24-212 - Round Electromagnet 1.375 inch Dia. 24 volts DC - Holding 44 lbs.
Outer Dia. (in): 1.375
Height (in): 0.81
Voltage: 24
Holding Force (lbs): 44
$30.86
1.375 0.81 24 44 $30.86
EM137-24-212-H - Round Electromagnet 1.375 inch Dia. 24 volts DC High Temp- Holding 44 lbs. image 0 EM137-24-212-H - Round Electromagnet 1.375 inch Dia. 24 volts DC High Temp- Holding 44 lbs.
Outer Dia. (in): 1.375
Height (in): 0.81
Voltage: 24
Holding Force (lbs): 44
$84.90
1.375 0.81 24 44 $84.90
Showing 37–48 of 203 results
