EML25mm-24 - Round Permanent Electromagnet 25 mm Dia. 24 volts DC - Holding 27 lbs. image 0

EML25mm-24 - Round Permanent Electromagnet 25 mm Dia. 24 volts DC - Holding 27 lbs.

$39.16
Skip to product information
EML25mm-24 - Round Permanent Electromagnet 25 mm Dia. 24 volts DC - Holding 27 lbs. image 0
SKU: 6677

EML25mm-24 - Round Permanent Electromagnet 25 mm Dia. 24 volts DC - Holding 27 lbs.

$39.16
Available on backorder.
** Backordered items typically ship in 3-5 business days. You will be contacted with a delivery date for any backordered items.
Quantity
Discount (%)
Price

Specifications

Length (mm)
29
Length (in)
1.14
Outer Diameter (mm)
25
Holding Force (Lbs.)
27
Ohms
82.76
Watts
6.96
Amps
0.29
Duty
Intermittent
Current
DC
Voltage
24
Encapsulation
Yes
Mounting Screw Supplied
No
Bolt Desc. or Thread
Metric Tapped M4
Mounting Option
Tapped Rear Threaded
Lead Wire Ga.
26
Lead Wire Type
UL 1007
Lead Wire Length (mm)
200

Description

The EML25mm-24 Round Permanent Electromagnet is a high-quality and precision-made product designed to operate on 24 volts DC. With a diameter of 25 mm and a holding capacity of 27 lbs, this electromagnet is ideal for use in a range of applications, such as material handling, magnetic separation, and clamping. The product is manufactured with the highest level of precision and quality to ensure reliable performance and durability. It is an excellent choice for mechanical and electrical engineers seeking a robust and efficient solution for their electromagnetic needs, and will perform exceptionally well in various settings.
