EM350-24-222 - Round Electromagnet 3.5 inch Dia. 24 volts DC - Holding 600 lbs.

$129.25
Skip to product information
EM350-24-222 - Round Electromagnet 3.5 inch Dia. 24 volts DC - Holding 600 lbs. image 0
SKU: 6425

EM350-24-222 - Round Electromagnet 3.5 inch Dia. 24 volts DC - Holding 600 lbs.

$129.25

8 in stock

Quantity
Discount (%)
Price

Specifications

Height (mm)
50.8
Height (in)
2
Outer Diameter (mm)
88.9
Outer Diameter (in)
3.5
Holding Force (Lbs.)
600
Ohms
16.78
Watts
34.32
Amps
1.43
Duty
Continuous
Current
DC
Voltage
24
Magnetic Stainless 430FR
No
High Temperature (500 F)
No
Anti-Rotation Pin
No
Encapsulation
No
Quick Release
No
Mounting Screw Supplied
No
Bolt Desc. or Thread
Tapped 1/4-20 2 pl.
Mounting Option
Tapped Rear Threaded
Lead Wire Ga.
18
Lead Wire Type
UL
Lead Wire Length (mm)
457.2

Description

The EM350-24-222 Round Electromagnet is a highly efficient and reliable product designed for a range of industrial applications that require strong magnetic holding power. This 3.5-inch diameter electromagnet is capable of holding up to 600 lbs when powered with 24 volts DC. It is precision-made with high-quality materials and components, ensuring optimal performance and longevity. This electromagnet is ideal for use in robotics, automation systems, and manufacturing equipment that require strong magnetic holding forces to secure and position components or parts with ease and accuracy.
