EM200-24ac-212 - Round Electromagnet 2 inch Dia. 24 volts AC - Holding 140 lbs. image 0

EM200-24ac-212 - Round Electromagnet 2 inch Dia. 24 volts AC - Holding 140 lbs.

$53.21
Skip to product information
EM200-24ac-212 - Round Electromagnet 2 inch Dia. 24 volts AC - Holding 140 lbs. image 0
SKU: 4739

EM200-24ac-212 - Round Electromagnet 2 inch Dia. 24 volts AC - Holding 140 lbs.

$53.21
Available on backorder.
** Backordered items typically ship in 3-5 business days. You will be contacted with a delivery date for any backordered items.
Quantity
Discount (%)
Price

Specifications

Height (mm)
29.97
Height (in)
1.18
Outer Diameter (mm)
50.8
Outer Diameter (in)
2
Holding Force (Lbs.)
140
Ohms
82.76
Watts
6.96
Amps
0.29
Duty
Continuous
Current
AC
Voltage
24
Magnetic Stainless 430FR
No
High Temperature (500 F)
No
Anti-Rotation Pin
No
Encapsulation
Yes
Quick Release
No
Mounting Screw Supplied
Yes
Bolt Desc. or Thread
1/4-20 x 1 1/4
Mounting Option
Through-Hole w/ Shoulder Bolt
Lead Wire Ga.
18
Lead Wire Type
UL
Lead Wire Length (mm)
457.2

Description

The EM200-24ac-212 is a high-quality precision-made round electromagnet with a diameter of 2 inches and the ability to hold up to 140 lbs. It operates on 24 volts AC and is designed for use in a variety of applications that require strong holding forces. Its robust construction and reliable performance make it an ideal solution for use in industrial automation, material handling, and robotics applications. The electromagnet is engineered to strict standards and is built to withstand the harsh conditions of industrial environments, ensuring dependable operation for years to come.
