EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs. image 0

EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs.

$59.75
Skip to product information
EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs. image 0
  • EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs. image 0
  • EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs. image 1
EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs.
SKU: 4741

EM200-110-212 - Round Electromagnet 2 inch Dia. 110 volts DC - Holding 140 lbs.

$59.75
Available on backorder.
** Backordered items typically ship in 3-5 business days. You will be contacted with a delivery date for any backordered items.
Quantity
Discount (%)
Price

Specifications

Height (mm)
29.97
Height (in)
1.18
Outer Diameter (mm)
50.8
Outer Diameter (in)
2
Holding Force (Lbs.)
140
Ohms
1833.33
Watts
6.6
Amps
0.06
Duty
Continuous
Current
DC
Voltage
110
Magnetic Stainless 430FR
No
High Temperature (500 F)
No
Anti-Rotation Pin
No
Encapsulation
Yes
Quick Release
No
Mounting Screw Supplied
Yes
Bolt Desc. or Thread
1/4-20 x 1 1/4
Mounting Option
Through-Hole w/ Shoulder Bolt
Lead Wire Ga.
18
Lead Wire Type
UL
Lead Wire Length (mm)
457.2

Description

The EM200-110-212 is a high-powered round electromagnet designed for heavy-duty applications requiring a 140 lb holding force. The product features a 2-inch diameter and operates on 110 volts DC, making it ideal for use in industrial and manufacturing settings. Precision-made with high-quality materials, this electromagnet provides reliable and consistent performance. Applications include metalworking, material handling, and automation processes where secure and efficient lifting and holding are necessary. The EM200-110-212 offers exceptional holding force and performance, making it an essential component in heavy-duty electromechanical systems.

SKU: 4741
Category: Electromagnets , Round Electromagnets
Tags: 0.06 , 1/4-20 x 1 1/4 , 110 , 110 Volts DC , 140 , 2 inch Diameter , Continuous , DC , Electromagnets , Electromagnets > Round Electromagnets , EM200-110-212 , Holding 140 lbs , Industrial Magnet , Magnetic Attraction , Magnetic Field , Magnetic Force , No , Permanent Magnet , Round Electromagnet , Round Electromagnets , Through-Hole w/ Shoulder Bolt , Yes
