EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs. image 0

EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs.

$47.88
Skip to product information
EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs. image 0
  • EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs. image 0
  • EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs. image 1
EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs.
SKU: 5751

EM175-115ac-222 - Round Electromagnet 1.75 inch Dia. 115 volts AC - Holding 100 lbs.

$47.88
Available on backorder.
** Backordered items typically ship in 3-5 business days. You will be contacted with a delivery date for any backordered items.

Specifications

Height (mm)
31.75
Height (in)
1.25
Outer Diameter (mm)
44.45
Outer Diameter (in)
1.75
Holding Force (Lbs.)
100
Ohms
2300.0
Watts
5.75
Amps
0.05
Duty
Continuous
Current
AC
Voltage
115
Magnetic Stainless 430FR
No
High Temperature (500 F)
No
Anti-Rotation Pin
No
Encapsulation
No
Quick Release
No
Mounting Screw Supplied
Yes
Bolt Desc. or Thread
1/4-20 x 1 1/4
Mounting Option
Through-Hole w/ Shoulder Bolt
Lead Wire Ga.
22
Lead Wire Type
UL
Lead Wire Length (mm)
457.2

Description

EM175-115ac-222 is a high-performance round electromagnet with a diameter of 1.75 inches and a holding capacity of 100 lbs. This precision-made product is designed for use in various applications, including industrial automation, material handling, and robotics. Its high-quality construction and 115 volts AC power supply make it a reliable and effective tool for lifting and holding heavy loads. The compact design of the electromagnet makes it easy to integrate into existing machinery, and its durability ensures long-lasting performance in harsh environments.

SKU: 5751
Category: Electromagnets
Tags: 0.05 , 1.75 inch Diameter , 1/4-20 x 1 1/4 , 100 , 100 lbs Capacity , 115 , 115 volts AC , AC , Continuous , Electromagnet , Electromagnets > Round Electromagnets , Holding Power , Industrial Magnet , Magnetic Attraction , Magnetic Field , Magnetic Force , No , Round Magnet , Through-Hole w/ Shoulder Bolt
